Stonewall

In: Generators

Description

Use the Stonewall filter to quickly embed your material into an old stone wall.

Parameters

Basic parameters

  • Random Seed:
    The random seed that all other random parameters in this filter is based on.
  • Stone Pattern:
    Select which pattern is used to arrange the stones
  • Stones Amount: 4-18
    Adjust the number of stones to break the material into
  • Stone Roundness: 0-1
    Control the wear of the stone's edges
  • Stones Flatten Amount: 0-1
    Adjust the relative height of the stones to the mortar between the stones
  • Mortar Thickness: 0-1
    Adjust how much space there is between stones
  • Mortar Height: 0-1
    Increase or decrease the height of the mortar between stones
  • Mortar Color: color select
    Adjust the color of the mortar between stones
  • Grime Amount: 0-1
    Change the amount of grime and dirt applied to the material
  • Grime Color: color select
    Select the color of the grime

Advanced Parameters

  • Normal Intensity: 0-3
    Control the strength of the normals for the entire material.
